DT7540.47: Beacon Sounder Acknowledge, Horizontal, Stainless

To improve customer experience and monitor performance, this website uses Folknoll Group and third‑party cookies. By continuing to use this website, you accept this practice.

Features

  • Combined beacon sounder and acknowledge button
  • Large, bright, 20mm, dome shaped LED beacon
  • Integral sounder
  • Vandal resistant, acknowledge button
  • Tough, vandal resistant, brushed finish, stainless steel plate
  • Black silk screened annotation
  • Mounts in a standard UK, 35mm, double gang, back box
  • Anti‑tamper fixings available on request
  • Adds acknowledge function to legacy back boxes

Our Disabled Toilet Alarm Range

Our vandal resistant emergency assistance alarm range offers tough, cost‑effective, BS 8300‑2 and document M compatible systems suitable for public use. We supply stand‑alone alarms, multiple alarm systems with remote monitoring and combined systems with disabled refuge EVCS, building alarms, etc. For larger and smarter sites, we offer networked solutions with optional BMS interfaces. Ideal for hospitals, railway stations, hotels, airports and other public spaces.

Beacon Sounder Acknowledge, Horizontal, Stainless

Our DT7540.47 is fitted with a large bright LED beacon and an internal sounder to give visual and audible indication of the source of activated alarms. The LED beacon is dome shaped and can be seen from the side, ideal for mounting in corridors. The unit also has an acknowledge button to activate a timed BS 8300‑2 compatible acknowledge function.

The front panel is made from brushed finish stainless steel and annotated in black. Other finishes and alternative annotation are available on request. This unit can be mounted in a standard UK, 35mm, double gang, back box.

Specifications


Beacon
Large, bright red, 20mm dome LED (other colours on request)
Sounder
Internal buzzer
Acknowledge point
Large, vandal‑resistant, push button
Input voltage
12Vdc / 24Vdc (please specify when ordering)
Front plate
Stainless steel (304/1.4301), brushed finish (other finishes on request)
Annotation
Black, silk screened (other options on request)
Plate dimensions
Width: 146mm, height: 86mm, depth: < 35mm (approx.)
Plate mounting
Standard UK, 35mm, double gang, back box (not supplied)

Suitable for
